| Gear Ratio | 157:1 |
|---|---|
| Approx. Unit Weight | 1,875 lb (836.87 kg) |
| Standard Motor | 128/064 (12.8/6.4 CID) 2-Speed |
| Drum Size | 9” (229 mm) Barrel x 20” (508 mm) Flange x 20” (508 mm) Between Flanges |
| Rope Diameter | 1-1/8” (29 mm) |
| D/d Ratio (Wire Rope) | 8:1 |
| Layer 1 | Layer 2 | Layer 3 | Layer 4 | |
| Line Pull* LOW HIGH |
130,000 lb (58,967 kg) 58,070 lb (26,340 kg) |
106,360 lb (48,244 kg) 47,510 lb (21,550 kg) |
90,000 lb (40,823 kg) 40,200 lb (18,234 kg) |
78,000 lb (35,380 kg) 34,840 lb (15,803 kg) |
| Line Speed* LOW HIGH |
23 fpm (6.9 mpm) 45 fpm (13.7 mpm) |
28 fpm (8.4 mpm) 55 fpm (16.8 mpm) |
33 fpm (9.9 mpm) 65 fpm (19.8 mpm) |
38 fpm (11.4 mpm) 75 fpm (22.9 mpm) |
| Drum Capacity 1-1/8” (29 mm) |
42 ft (12.8 m) |
94 ft (28.7 m) |
155 ft (47.2 m) |
226 ft (68.9 m) |
