HP125B

Recovery Winches

Rated Line Pull: 125,000 lb (56,699 kg)
Gear Ratio 157:1
Approx. Unit Weight 1,825 lb (828 kg)
Standard Motor 128/064 (12.8/6.4 CID) 2-Speed
Drum Size 9” (229 mm) Barrel x 20” (508 mm) Flange x 20” (508 mm) Between Flanges
Rope Diameter 1-1/8” (29 mm)
D/d Ratio (Wire Rope) 8:1
Specifications are representative of common configuration. Consult factory for additional options.
Download HP Series Brochure

Performance

Layer 1 Layer 2 Layer 3 Layer 4
Line Pull*
LOW

HIGH
125,000 lb
(56,800 kg)
55,200 lb
(25,100 kg)
102,300 lb
(46,500 kg)
45,150 lb
(20,500 kg)
86,500 lb
(39,300 kg)
38,200 lb
(17,400 kg)
75,000 lb
(34,100 kg)
33,100 lb
(15,000 kg)
Line Speed*
LOW

HIGH
14 fpm
(4 mpm)
31 fpm
(9 mpm)
17 fpm
(5 mpm)
38 fpm
(12 mpm)
20 fpm
(6 mpm)
45 fpm
(14 mpm)
23 fpm
(7 mpm)
52 fpm
(16 mpm)
Drum Capacity
1” (25 mm)
1-1/8” (29 mm)
1 1/4” (32 mm)
47 ft (14.3 m)
42 ft (12.8 m)
38 ft (11.6 m)
103 ft (31.4 m)
93 ft (28.3 m)
86 ft (26.2 m)
168 ft (51.2 m)
154 ft (46.9 m)
142 ft (43.3 m)
243 ft (74.1 m)
224 ft (68.3 m)
209 ft (63.7 m)
*Based on pressure of 2,600 psi (179 bar), 60 gpm (227 lpm), 1-1/8” in (29 mm) rope and 12.8/6.4 CID motor.
Actual performance will vary dependent on hydraulic system, motor, drum and cable sizes.

Dimensions
