| Winch | 12,000 lb (5,443 kg) |
|---|---|
| System Weight* | 495 lb (224 kg) |
| Vehicle Compatibility | Medium Duty, Class 4 |
| Rope Diameter | 3/8” (10 mm), 7/16" (11 mm), 1/2” (13 mm) |
| Extension Shaft | Streetside (standard) or Curbside (optional) |
| Accessories | Standard: Roller Fairlead Options: Aluminum or Ductile Iron Capstan |
| Customization | Cone Racks, Tow Hooks, Tie Downs, Storage, Custom Branding, Custom Paint |
| Layer 1 | Layer 2 | Layer 3 | Layer 4 | Layer 5 | Layer 6 | |
|---|---|---|---|---|---|---|
| Line Pull* | 12,000 lb (5,443 kg) | 9,810 lb (4,450 kg) | 8,300 lb (3,765 kg) | 7,200 lb (3,266 kg) | 6,350 lb (2,880 kg) | |
| Line Speed* | 46 fpm (14.0 mpm) | 56 fpm (17.1 mpm) | 66 fpm (20.2 mpm) | 77 fpm (23.3 mpm) | 87 fpm (26.4 mpm) | |
| Rope Capacity** 3/8” (10 mm) 7/16” (11 mm) 1/2” (13 mm) | 37 ft (11.3 m) 32 ft (9.8 m) 28 ft (8.5 m) | 81 ft (24.7 m) 71 ft (21.6 m) 64 ft (19.5 m) | 132 ft (40.2 m) 117 ft (35.7 m) 106 ft (32.3 m) | 188 ft (57.3 m) 169 ft (51.5 m) 154 ft (46.9 m) | 252 ft (76.8 m) 227 ft (69.2 m) 209 ft (63.7 m)† | 322 ft (98.1 m)† |
