UBX Bumper System

Specialty Products

Rated Line Pull: 20,000 lb (9,072 kg)
Download Utility Bumper Systems Brochure
WinchTR20
System Weight*680 lb (308 kg)
Vehicle CompatibilityMedium Duty, Class 5-7
Rope Diameter1/2” (13 mm), 9/16” (14 mm), 5/8” (16 mm)
Extension ShaftCurbside
ToolboxSingle
CustomizationAluminum or Ductile Iron Capstan
Provision for Collision Mitigation System
Roller or Hawse Fairlead
*Does not include rope.

Performance

Layer 1Layer 2Layer 3Layer 4Layer 5Layer 6Layer 7
Line Pull*20,000 lb
(9,072 kg)		16,970 lb
(7,697 kg)		14,740 lb
(6,686 kg)		13,030 lb
(5,910 kg)		11,670 lb
(5,293 kg)		10,570 lb
(4,794 kg)
Line Speed*25.7 fpm
(7.8 mpm)		30.2 fpm
(9.2 mpm)		34.8 fpm
(10.6 mpm)		39.4 fpm
(12 mpm)		44 fpm
(13.4 mpm)		48.6 fpm
(14.8 mpm)
Rope Capacity
1/2” (13 mm)

9/16” (14 mm)

5/8” (16 mm)
25 ft
(7.6 m)
22 ft
(6.8 m)
20 ft
(6.2 m)
54 ft
(16.5 m)
49 ft
(14.9 m)
45 ft
(13.7 m)
87 ft
(26.5 m)
79 ft
(24.2 m)
73 ft
(22.3 m)
124 ft
(37.8 m)
114 ft
(34.7 m)
106 ft
(32.2 m)
165 ft
(50.3 m)
152 ft
(46.5 m)
142 ft
(43.3 m)
210 ft
(64 m)
195 ft
(59.3 m)
259 ft (79 m)
*Based on pressure of 2,500 psi (172 bar), 20 gpm (76 lpm) and 9.6 CID motor with 9/16” (14 mm) rope.
Actual performance will vary dependent on hydraulic system, motor, drum and cable sizes. Rope capacity based on 90% of theoretical.

Dimensions
