PD18 Bumper System

Specialty Products

Rated Line Pull: 20,000 lb (9,072 kg)
Winch PD18C
System Weight* 780 lb (354 kg)
Vehicle Compatibility Medium Duty, Class 5-7
Rope Diameter 1/2” (13 mm), 9/16” (14 mm), 5/8” (16 mm)
Extension Shaft Curbside or Streetside
Toolbox Single or Dual
Customization Aluminum or Ductile Iron Capstan
Roller or Hawse Fairlead
*Does not include rope.
Download Utility Bumper Systems Brochure

Performance

Layer 1 Layer 2 Layer 3 Layer 4 Layer 5 Layer 6 Layer 7
Line Pull* 20,000 lb
(9,072 kg)		 17,100 lb
(7,756 kg)		 15,000 lb
(6,804 kg)		 13,300 lb
(6,033 kg)		 11,900 lb
(5,398 kg)		 10,800 lb
(4,899 kg)
Line Speed* 42 fpm
(12.8 mpm)		 49 fpm
(14.9 mpm)		 56 fpm
(17.1 mpm)		 63 fpm
(19.2 mpm)		 70 fpm
(21.3 mpm)		 77 fpm
(23.5 mpm)
Rope Capacity
1/2” (13 mm)

9/16” (14 mm)

5/8” (16 mm)
37 ft
(11.3 m)
33 ft
(10.1 m)
30 ft
(9.1 m)
79 ft
(24.1 m)
71 ft
(21.6 m)
65 ft
(19.8 m)
126 ft
(38.4 m)
114 ft
(34.7 m)
105 ft
(32 m)
178 ft
(54.3 m)
162 ft
(49.4 m)
150 ft
(45.7 m)
235 ft
(71.6 m)
216 ft
(65.8 m)
201 ft
(61.3 m)
298 ft
(90.8 m)
275 ft
(83.8 m)**
257 ft
(78.3 m)**
366 ft
(111.6 m)**
*Based on pressure of 2,450 psi (169 bar), 30 gpm (113.5 lpm) and 11.9 CID motor with 5/8” (16 mm) rope.
**PD18C with -11/14 drum only. Actual performance will vary dependent on hydraulic system, motor, drum and cable sizes.
Rope capacity based on 90% of theoretical.

Dimensions
